• Supports up to 1950 horsepower
• 88mm compressor inducer | 133mm compressor exducer
• 112mm turbine inducer | 106mm turbine exducer
• 15% more turbine flow (compared to GTX) see graph below
• One-piece aluminum center housing
• 16mm ceramic dual ball bearing cartridge
• Outline interchangeable with GTX Gen II turbos
• Stainless Steel turbine kit sold individually.
• T6 Inlet: 1.00 A/R, 1.12 A/R, 1.24 A/R, 1.40 A/R
• V-Band Inlet: 1.24 A/R, 1.40 A/R

G55-1950 (88mm Compressor Inducer) 880547-5002S

G-SERIES G55-1850 85MM

Reference Data

G Series G55		Compressor				Turbine
Supercore PN	Model	Inducer	Exducer	Trim	A/R	Inducer	Exducer	Trim
880547-5001S	G55-1850	85mm	133mm	41	0.88	112	106	90
880547-5002S	G55-1950	88mm	133mm	44	0.88	112	106	90
880547-5003S	G55-2100	91mm	133mm	47	0.96	112	106	90
880547-5004S	G55-2250	94mm	133mm	50	0.96	112	106	90
880547-5005S	G55-2450	98mm	133mm	54	0.96	112	106	90
880547-5021S	G55-2650	102mm	144mm	54	0.96	112	106	90
880547-5022S	G55-2900	106mm	144mm	54	0.96	112	106	90
Notes:		Turbine Kit PN	A/R	Inlet	Outlet	Wastegate	Divided	Trim
Supercore and Turbine Kit Sold Separately		761208-0069	1.24	V-band	V-Band	Free Float	N	90
		761208-0070	1.40	V-band	V-Band	Free Float	N	90
		761208-0071	1.00	T6	V-Band	Free Float	N	90
		761208-0072	1.12	T6	V-Band	Free Float	N	90
		761208-0073	1.24	T6	V-Band	Free Float	N	90
		761208-0074	1.40	T6	V-Band	Free Float	N	90

G-SERIES G55-1850 85MM

Download Section

The latest Garrett technologies featuring many advanced features.

File Name	Link	View
Compressor Map 85MM Inducer	Download	View
Compressor Map 88MM Inducer	Download	View
Compressor Map 91MM Inducer	Download	View
Compressor Map 94MM Inducer	Download	View
Compressor Map 98MM Inducer	Download	View
Compressor Map 102MM Inducer	Download	View
Compressor Map 106MM Inducer	Download	View

File Name	Link	View
Configuration Guide	Download	View

File Name	Link	View
Compressor Map	Download	View
Exhaust Flow Chart	Download	View
Product Photo	Download	View
Flange Diagram	Download	View
Speed Sensor Kit Installation Instruction	Download	View
