With a crisp, clear and full colour display, the all new Haltech IC7 Display Dash lets you see things in a brand new way. HT-067010 HT-067012

Designed and manufactured in Australia with motoring enthusiasts in mind, the IC-7 offers market-leading features in a unique, state-of-the-art package.

Featuring auto-dimming ambient light reactive brightness, user-programmable multi-colour shift light bar, the IC-7 connects directly to all current Haltech ECUs via a CAN network. The IC-7 can also connect directly (via CAN) to most late model vehicles using the factory OBD-II port.

Ideal replacement for individual analogue gauge clusters.
Easy to install and configure.
User adjustable brightness control with automatic dimming.
User configurable channels, units and alarms.
14 programmable, seven colour shift light LEDs.
Controlled via easily accessible, face-mounted control buttons.
Configuration via Haltech IC-7 software and USB cable.
Screen size: 7in. Case size: 217 x 122mm (8.5³ x 4.8³)

Download the IC-7 Quick Start Guide Here

Part Number: HT-067010

Screen: Full colour 7" TFT display
Outside Dimensions: 217 x 122mm (8.5³ x 4.8³)
Compatible with: All currrent Haltech ECUs via CAN.

What's in the box:

Haltech iC-7 Display Dash
34 Pin main connector harness
DTM-4 to DTM-4 CAN extension cable
USB to M5 right angle cable
USB Cable
Mounting Screws
USB flash drive with iC-7 Software
Quick Start Guide
Haltech stickers and a fabric keyring tag

Part Number: HT-067012

Screen: Full colour 7" TFT display
Outside Dimensions: 217 x 122mm (8.5³ x 4.8³)
Compatible with: OEM ECUs via OBD-II (CAN only)

What's in the box:

Haltech iC-7 Display Dash
34 Pin main connector harness
DTM-4 to OBD-II CAN Cable
USB to M5 right angle cable
USB Cable
Mounting Screws
USB flash drive with iC-7 Software
Quick Start Guide
Haltech stickers and a fabric keyring tag

Optional Mounting Accessories

Universal Mounting Bracket

Mounting Bracket with Integrated Visor

Billet Bar Mount

Haltech IC-7 Software

The IC-7 is configured using a brand new, intuitive software. With this software you can change various aspects of the dash behaviour including:

Ranges of channels. Eg. the maximum RPM on a needle style tacho or a bar graph.
Red ranges for channels. Eg. when a numeric display changes to red, red zone on a tacho.
Display units. Eg. metric or imperial, Lambda or AFR.
The channel to be displayed at each location on the screen.
The connection method. Eg. Haltech CAN or OBD-II.
Shift light RPM points and colours.
Alarm thresholds, colour for on-screen display and shift lights, manual or auto reset methods.
