Description:

Direct fit for the 1986“1992 MKIII Toyota Supra 3.0L
Applicable for both turbo and non-turbo models
Full aluminum construction including durable, TIG-welded end tanks
Features a two-row, 2.2" thick, efficient brazed aluminum core
Increased fluid capacity and optimal heat dissipation
Provides efficient temperature reduction for use on the street or track
Includes 1.3 Bar High-Pressure Radiator Cap which effectively raises the boiling point of engine coolant, providing a safer and more efficient system
Includes Magnetic Drain
Plug to capture any metallic debris/fragments in your cooling system
Mishimoto Lifetime Warranty

MaterialAluminum

NoteThis item is for Manual Transmission vehicles. For automatic applications, please purchase optional Mishimoto Universal Transmission Cooler Kit.

Chassis CodesMA70JZA70

Engine Codes7MGE7MGTE

Overall Height26.5"

DPI196

Drain Plug Length0.047"

Drain Plug Thread Size(M16) .06

Overall Length20.2"

Tank Wall Thickness0.08"

Outlet1.25"

Rows2

Inlet1.25"

Coolant Capacity2.45

Dual PassFalse

Purchase IncludesMishimoto Radiator
Mishimoto Radiator Cap
Magnetic Drain Plug
Mishimoto Lifetime Warranty

Overall Width2.7"

Core Length14.76"

Core Height25.12"

Core Thickness2.2"

Fill Neck1.25"
