Goleby's Parts purchased this Ke36 Panelvan back in around 2012 with the intention of using it as a parts delivery Van for the business, The car was purchased for $500 running and driving with a 5k engine and 5 speed gearbox.

First Build,

The first build of our corolla was a turbocharged 4k engine, the engine internals were all standard except for a set of upgraded Valve springs and using a single Ct12A turbocharger blowing through a 32/36 weber carburetor we made 160rwhp. This build then upgraded to Efi with the help of a Microtech ecu, custom intake manifold and injector setup with the end result being 180rwhp with e85 and 24psi of boost. At this stage we had a Trimatic auto gearbox and standard diff still fitted and managed a best 1/4 mile of 13.8 seconds (logged via the GPS Microtech dash).

Around 5000kms driven on this setup.



Second Build,

One Friday afternoon we thought about the great idea of building a reliable 10 second daily whilst not breaking the bank, so we set ourselves a budget of around $10k to see what we could achieve. Out came the grinder and the stock internal 1JZ engine was mounted in the engine bay by the end of the weekend.



The basic run down of this setup was as follows,



Standard internal 1JZGTE non Vvti engine

Precision 5858 Journal bearing turbo

Turbosmart 45mm wastegate

Custom 2-1 exhaust manifold

Microtech lt15c ecu

1000cc injectors

Bosch 044 Fuel pump

Standard A340 gearbox with upgraded valve body and convertor

PWR trans cooler

Stock RN10 hilux diff with hilux LSD

Stock Xt130 corona front struts and brakes

450 x 300 x 76 mm intercooler

3" exhaust

All this turned into 500RWHP at 33psi and 10.3 Quarter mile times, and continued this way for a year or so. Around 10000kms travelled on this setup.

Third Build,

This is where we got more serious and added some HP with the following parts,

282 Camtech Cams

Supertech valve springs and retainers

Built A340 gearbox

Plazmaman 600x300x76 intercooler

Haltech PS2000

Precision 6870 Turbocharger

Twin 044 Bosch fuel pumps

Bosch 1600cc injectors

Plazmaman intake manifold

Goleby's Parts Yaris coil kit

With these upgrades power jumped to 730RWHP and got us into 8 seconds over the 1/4 mile at 154mph. Around 20000kms travelled on this setup.



After this is when the final and current build took place with a more detailed list below,





Precision 7275 Turbocharger

Turbosmart Gen V 50mm Red Pro-Gate Wastegate

Turbosmart Gen V Red Raceport

6Boost Custom V-Band High Mount Manifold

Goleby's Parts Turbo Beanie









Plazmaman 1JZ-GTE Black Billet Intake Manifold

72mm Throttle Body, Single 6 injector fuel rail

Plazmaman Pro Series Intercooler - 600 x 300 x 76

Custom Intercooler Piping using Goleby's clamps / Silicone joiners







GRT (Gilroy's Race Transmissions) Built A340

GRT 4500 RPM Converter

PWR 28 Row Oil Cooler + Spal Fan

RN10 Hilux Diff, standard Axles, 3.5 ratio, aftermarket LSD centre

XT130 Front struts and brakes with DBA Slotted Rotors and Brake Pads

Standard suspension Front and Rear with Whiteline rear swaybar and custom traction arms







Haltech Elite 2500T + Custom Terminated Harness

Haltech WBC-1

Haltech Dash

PRP R35 Coil Kit

Bosch Motorsports Sensors

Haltech Sensors







Bosch Motorsport Australia 1650cc Injectors

Turbosmart FPR 1200 V2

2 x Bosch Motorsports 200 (044 V2) Fuel Pumps

Goleby's Parts Feed & Return Lines

Speedflow Billet Fuel Filter

Custom Fuel Cell







Toyota 1JZ-GTE VVT-I

Goleby's Parts 900hp Package

CP Pistons 9:0:1 Compression

Spool Imports I Beam Conrods

ARP Main Studs

ACL Race Big End & Main Bearings

Goleby's Parts Modified Toyota 2JZ-GTE Oil Pump

Kelford Cams V229-D 272/278 Cams

Kelford Cams KVS109-1JZ Valve Springs

CNC Ported Head

Brian Crower Intake & Exhaust Valves

Toyota Shim less Bucket Conversion

ARP 203-4205 Head Studs

GRP Full Gasket Kit

Gates Racing Timing Kit + Goleby's Parts + Ross Engineering Billet Tensioner

Toyota Water Pump

Ross Performance Parts Race Series Harmonic Balancer







14" Toyota Corona steel rims,

Fronts standard 14 x 5", rears Modified to 15 x 8"

235/60-15 MT radial rear tyres







2 x Velo Bucket Seats

PWR Radiator

Goleby's Parts Silicone Radiator Joiners

Goleby's Parts Fittings and hose Throughout



Performance Results,

Winner QLD Roll racing

Flying 500 entrant 230kmh (driven 1500km round trip)

Sydney Jamboree entrant (driven 1500km round trip)

Best ET 8.77 (770hp)

Best MPH 158 (820hp)

Current 898hp at the hubs 36psi



Currently around 10000kms Travelled on this setup (2022)

Still used for delivery duty's at Goleby's Parts to this day.
